How does the shuttle racking system consider the unitization of goods
Classification:
FAQ
Release time:
2021-03-25
The main idea in the design of shuttle rack structure is:
1. Systematic analysis and classification of customers’ stored goods, study the morphological changes of each unit in the entire logistics process, logistics path and work cycle, in and out frequency and access form, etc., carry out unit planning, and analyze the entire logistics process clearly. ；
2. Continuously split, classify and combine storage units, combine customer packaging and operation management models, introduce industry and regional unitized logistics standards, and formulate unitized recommendations that are in line with the long-term development of the company and logistics operation management, and are effective Improve the customer's logistics management level and management efficiency to ensure that the pallet and pallet structure in the shuttle rack storage unit of the matching design can be rationally unitized;
3. It is classified into a unified cargo unit form with a pallet or pallet structure as the base form and accurately defined, and the unitized weight does not exceed 1.5 tons, and the series of standard specifications that can be formed are as small as possible. This can reduce the customer’s unitized packaging and handling specifications, improve handling and circulation efficiency, reduce storage and transportation costs, and increase economic benefits. It can also easily help customers improve the mechanization and automation of handling operations, reduce the labor intensity of workers, and improve The working conditions and the level of logistics operation management at the production site can also prevent the loss of goods and the degradation of product quality caused by knocks, bumps, and scratches during the transportation process.
With the subdivision of market products and the improvement and standardization of unitized logistics in the future, companies will also be able to concentrate on developing and improving the quality of a certain series of products, improving product technology levels, and developing a more complete multi-functional application software and hardware environment. And design a reasonable shuttle rack structure accordingly.
Which contains:
1. Forklift operation space that can be easily picked up, and static and dynamic load capacity that can bear the weight of the pallet unit, the supporting design has a good dynamic and static structure and a shuttle support rail and a docking structure of the rail with a good dynamic and static structure and force support;
2. From the unit weight, deformation, clearance and handling error of the storage unit, the movement characteristics of the shuttle, and extensive actual load test verification, the supporting design has good movement characteristics and a reasonable structure of the shuttle;
3. According to the movement and control requirements of the shuttle, design deceleration holes and positioning holes that conform to the unitized size on the shuttle rack rails.
In addition, according to the unitized data of the storage unit, it is easy to determine the load form of the shuttle rack structure and the mechanical modeling analysis structure, and it can analyze and calculate the bearing capacity of the rack column and its column pieces, beams, and shuttle rails in detail. In addition to structural stability analysis, it can also be combined with customers for special case analysis and structural optimization for non-working conditions such as earthquakes.
Reasonably design the overall structure and supporting structure of the shelf to ensure the overall load-bearing capacity and stability of the shelf structure, but also to ensure the smooth and efficient operation of the shuttle in the shelf structure; the shelf structure can be combined through the principle of unitization and multiplication. Transformed into modular block design can greatly reduce the design error rate, improve the efficiency of design and planning, and further improve the efficiency of internal operations of the enterprise; standardize the operation process of the customer’s unitized items to ensure the follow-up operation process Smoothly and the safety of the shelf, the storage operation port of the upper and lower shelves is equipped with pallet guides, forklift stoppers, and shelf column protection devices. Similarly, in order to more effectively adapt to the floor level and possible ground subsidence of the customer site, the shuttle rack structure is also equipped with adjustable feet and other design structures.
Key words:
Shuttle,racking,system
